Pattern Width / Spacing Measurement Machine

Benefits

It is an automatic measurement system designed for PCB manufacturer.
- Directly import the CAM data and assign inspection locations. Machine accesses pattern measurement automatically according to preset locations.
- Full automation (inline type) and semi automation are available for intelligent factory.
- Utilize CCD to capture image for measurement to avoid direct contact, and hence no scratch occurs.
- Dramatically increases efficiency and avoid visual measurement error compared to human measurement.
- Avoid potential damage / scratching by human handling, especially for thin panel.
- Image and measurement data could be saved and export for SPC analysis and engineering report.

Featuers

- Measures pattern width / spacing of line, pad and gold finger and any other pattern.
- Width of both pattern top and bottom could be measured and recorded.
- Measurement points could be assigned by working on user-friendly interface with imported CAM data.
